Basic Info.

• Item Fit: TM03, PHV-2B, JMV16, 700-2C2K Travel Motors
• Item Condition: New
• Item Weight: 1.5-2.5 ton
• Item Maker: FLundercarriage
• Place of Origin: Quanzhou

Delivery Info.

• Inventory Class: Standing
• Packaging: Carton/Pallet
• ETD: 24-72 Hours
• ETA: 5-30 Days

Introduction:

The MAG-18V-230 Travel Motor is engineered for medium-slow speed crawler vehicles, offering medium-high torque capabilities. It combines a simple planetary speed reducer with a swash plate motor, supporting two-speed switching and optional installation of a parking brake.

Model Specifications:

• Model: MAG-18V-230
• Max Working Pressure: 21 MPa
• Max. Output Torque: 2100 N.m
• Max. Output Speed: 70 rpm
• Speed Control: 2-speed
• Oil Port: 4 ports

Key Features:

• Swash-plate piston motor with planetary reducer.
• Double-speed motor with versatile applications.
• Extremely compact and lightweight design.
• Ensures reliable quality and high durability.
• Operates smoothly with minimal noise.
• Optional automatic speed changing function.

Specifications:

• Motor Displacement: 9/16 cc/r
• Working Pressure: 21 MPa
• 2-Speed Control Pressure: 2~7 MPa
• Ratio Options: 39
• Max. Torque of Gearbox: 2100 N.m
• Max. Speed of Gearbox: 70 rpm

Connection Dimensions:

• Frame Flange Orientation Diameter: 150mm
• Frame Flange Bolt Pattern: 12-M10 Unequally
• Frame Flange Holes P.C.D.: 170mm
• Sprocket Flange Orientation Diameter: 160mm
• Sprocket Flange Bolt Pattern: 9-M10 Equally
• Sprocket Flange Holes P.C.D.: 180mm
• Flange Distance: 40mm
• Approximate Weight: 25kg

Summary:

The MAG series Hydraulic Final Drive Motor, including the MAG-18V-230, shares dimensions similar to renowned brands like Nachi, KYB, and Eaton. It is widely used in OEM and aftermarket applications, replacing various hydraulic final drive motors from brands such as Nachi, Kayaba, Eaton, Nabtesco, and more.
