Basic Info.

• Item Fit: Eaton JMV Axial Piston Motor, 2-speed Track Drive Motor JMV016
• Item Condition: New
• Item Weight: 1.5-2.5 ton
• Item Maker: FLundercarriage
• Place of Origin: Quanzhou

Delivery Info.

• Inventory Class: Standing
• Packaging: Carton/Pallet
• ETD: 24-72 Hours
• ETA: 5-30 Days

Overview:

JMV Series Track Drive Motor integrates a JMV Axial Piston Motor with a robust planetary gearbox, designed for a variety of applications including Mini Excavators, Drilling Rigs, Mining Equipment, and other Crawler Equipments.

Model Specifications:

• Model: JMV016
• Max Working Pressure: 21 MPa
• Max Output Torque: 1700 N.m
• Max Output Speed: 70 rpm
• Speed: 2-speed
• Oil Port: 4 ports

Key Features:

• Integrated gearbox with 2-speed Axial Piston Motor.
• Rated pressure up to 365 bar.
• Displacement: 16cc to 274cc.
• Suitable for mobile applications ranging from 1.5 tons to 50 tons.
• Integrated Relief and Counterbalance valves.
• Integrated fail-safe mechanical Parking Brake.
• Higher mechanical and volumetric efficiency to minimize power loss.
• Improved design for increased start-up torque and overall efficiency.
• Optimum design ensures smooth start, acceleration, and deceleration.
• Compact design with high power density.
• Auto-shift between high-speed low torque and low-speed high torque under high traveling resistance.
• High performance, reliability, and widespread market acceptance with over half a million units deployed.
• Compatible with most popular installation requirements in the market.

Connection Dimensions:

• Frame flange orientation diameter: 150mm
• Frame flange bolt pattern: 9-M10 Equally spaced
• Frame flange holes P.C.D. (Pitch Circle Diameter): 170mm
• Sprocket flange orientation diameter: 160mm
• Sprocket flange bolt pattern: 9-M10 Equally spaced
• Sprocket flange holes P.C.D.: 1580mm
• Flange distance: 40mm
• Approximate weight: 25kg

Flange hole patterns can be customized as per requirements.

Summary:

Typical Applications:

• Excavators and mini excavators
• Crawler cranes
• Winches
• Aerial working platforms
• Graspers
• Rotary drilling
• Horizontal directional drilling
• Crushers
• Asphalt milling
• Specialized crawler vehicles
