Basic Info.

• Item Fit: PMP Industries PMCI 1200 Integrated Travel Drive
• Item Condition: New
• Item Weight: 7-8 ton
• Item Maker: FLundercarriage
• Place of Origin: Quanzhou

Delivery Info.

• Inventory Class: Standing
• Packaging: Carton/Pallet
• ETD: 24-72 Hours
• ETA: 5-30 Days

Overview: The PMCI 1200 Integrated Travel Drive combines a Swash-plate Piston Motor with a planetary reducer gearbox. It is designed for track-driving hydraulic excavators, drilling rigs, mining equipment, and other crawler machinery.

Model Details:

• Model: PMCI 1200
• Max Working Pressure: 30 MPa
• Max. Output Torque: 11500 N.m
• Max. Output Speed: 50 rpm
• Speed: 2-speed
• Oil Port: 4 ports
• Motor Displacement: 34/53 cc/r
• Speed Control Pressure: 2~7 Mpa
• Ratio Options: 45.57

Key Features:

• Efficient Swash-plate Axial Piston Motor
• Dual-speed functionality with broad applicability
• Integrated parking brake for safety
• Compact and lightweight design
• High reliability and durability
• Smooth operation with minimal noise
• Optional Free-wheel device
• Optional automatic speed changing function

Connection Details:

• Frame Connection Diameter: 210mm
• Frame Flange Bolt: 12-M16
• Frame Flange P.C.D.: 250mm
• Sprocket Connection Diameter: 265mm
• Sprocket Flange Bolt: 12-M14
• Sprocket Flange P.C.D.: 300mm
• Flange Distance: 80mm
• Approximate Weight: 90kg

Summary: The PMCI 1200 Final Drive is an excellent replacement option for PMP Industries PMCI 1200 Travel Drive. It features high efficiency and robust strength, making it ideal for various mobile machinery applications. Fulian Machinery, renowned for producing high-performance OEM Final Drives, is a trusted supplier to top Chinese excavator brands. Discover why Fulian Machinery Final Drive stands out as your best resource for Track Motors in the market.
