Basic Info.

• Item Fit: DM05, GM06VA Travel Motors
• Item Condition: New
• Item Weight: 5-6 ton
• Item Maker: FLundercarriage
• Place of Origin: Quanzhou

Delivery Info.

• Inventory Class: Standing
• Packaging: Carton/Pallet
• ETD: 24-72 Hours
• ETA: 5-30 Days

Product Overview

PHV-4B Final Drive integrates a Swash-plate Piston Motor with a robust planetary gearbox, featuring a new design with increased ratio for higher torque output. It is extensively utilized in Agricultural Machinery, Excavators, Drilling Rigs, Mining Equipment, and other Crawler Equipment.

Key Features

• High Output Torque: Designed to deliver larger torque compared to conventional PHV-4B Motors.
• Efficient Swash-plate Axial Piston Motor: Ensures optimal operational efficiency.
• Two-speed Motor: Provides versatility with a large ratio for various applications.
• Built-in Parking Brake: Enhances safety during operation.
• Compact and Lightweight: Facilitates easy installation and handling.
• Reliable Quality: Ensures durability and longevity.
• Smooth Operation: Operates quietly with minimal noise.
• Optional Free-wheel Device: Adds flexibility in operation.
• Optional Automatic Speed Changing Function: Facilitates seamless speed adjustments.

Specifications

• Motor Displacement: 19/34 cc/r
• Working Pressure: 24.5 MPa
• Speed Control Pressure: 2~7 MPa
• Ratio Options: 58
• Max. Torque of Gearbox: 7,700 N.m
• Max. Speed of Gearbox: 54 rpm

Connection Details

• Frame Connection Diameter: 180mm
• Frame Flange Bolt: 9-M14
• Frame Flange P.C.D.: 220mm
• Sprocket Connection Diameter: 230mm
• Sprocket Flange Bolt: 12-M14
• Sprocket Flange P.C.D.: 262mm
• Flange Distance: 75mm
• Approximate Weight: 70kg (155lbs)

Summary

The PHV-4B Hydraulic Final Drive Motor shares compatible dimensions with major brands such as Nachi, KYB, Eaton, and others, making it a preferred choice in both OEM and aftermarket applications. Suitable for a wide range of Excavators from renowned brands, ensuring compatibility and reliability across diverse applications.
