Basic Info.

• Item Fit:
• Item Condition: New
• Item Weight: 5-6 ton
• Item Maker: FLundercarriage
• Place of Origin: Quanzhou

Delivery Info.

• Inventory Class: Standing
• Packaging: Carton/Pallet
• ETD: 24-72 Hours
• ETA: 5-30 Days

Overview:

The WBM-07NYD series Track Drive represents our latest innovation in Final Drive technology, integrating a high-efficiency travel motor with a robust planetary gearbox. These drives are tailored for a wide range of applications including Skid Steer Loaders, Compact Track Loaders, Pavers, Dozers, Soil Compactors, and other Crawler Equipment.

Model Specifications:

• Rated Working Pressure: 30 MPa
• Max. Output Torque: 7300 N.m
• Max. Output Speed: 80 rpm
• Speed: 2-speed
• Oil Port: 5 ports

Key Features:

• Designed for closed hydraulic circuits.
• Rated pressure of 30 MPa (300 bar) for high-pressure applications.
• Includes speed transducer for automatic vehicle control.
• High-speed capability up to 100 rpm.
• Built-in parking brake enhances safety.
• Compact and lightweight design.
• Ensures reliable quality with high durability.
• Operates smoothly with minimal noise.

Connection Dimensions:

• Frame orientation diameter: 240 mm
• Frame bolt pattern: 18-M16
• Frame holes P.C.D.: 275 mm
• Sprocket orientation diameter: 250 mm
• Sprocket bolt pattern: 9-M16
• Sprocket holes P.C.D.: 290 mm
• Flange distance: 110 mm
• Approximate weight: 85 kg

Both flange hole patterns can be customized as needed.

Summary:

The WBM-700 series Track Drive is specifically designed for closed-loop hydraulic systems, making it ideal for Skid Steer Loaders and Compact Track Loaders. These Final Drives share specifications and connection dimensions with Bonfiglioli's 700 series Track Drives, ensuring compatibility and ease of integration. Our products also offer interchangeability with leading brands such as Sauer-Danfoss BMVT, Nabtesco TH-VB, and DANA CTL Spicer Torque-hub. We can further tailor Motor size and connection configurations to match your OEM Final Drive requirements.

Wide Applications:

WBM Track Motors are compatible with a vast array of Track Loaders from renowned brands including BOBCAT, CASE, CATERPILLAR, JOHN DEERE, DITCH WITCH, and many others. They are engineered to deliver superior performance and reliability across diverse applications in the construction and agricultural sectors.
