Basic Info.

• Item Fit:
• Item Condition: New
• Item Weight: 7-9 ton
• Item Maker: FLundercarriage
• Place of Origin: Quanzhou

Delivery Info.

• Inventory Class: Standing
• Packaging: Carton/Pallet
• ETD: 24-72 Hours
• ETA: 5-30 Days

Introduction

The WBM-700CT series Track Drive is our newly designed final drive unit, integrating a high-efficiency hydraulic motor and a robust planetary gearbox. It finds extensive applications in Skid Steer Loaders, Compact Track Loaders, Pavers, Dozers, Soil Compactors, and other crawler equipment.

Specifications

• Rated Working Pressure: 27.5 MPa
• Max. Output Torque: 11500 N.m
• Max. Output Speed: 50 rpm
• Speed switching: 2-speed
• Oil Port: 5 ports

Key Features

• Designed for closed hydraulic circuits.
• Built-in flushing valve.
• High-efficiency axial piston motor.
• Dual-speed motor with a wide range of applications.
• Built-in parking brake for safety.
• Compact and lightweight design.
• Reliable quality and high durability.
• Smooth operation with low noise levels.
• Optional automatic speed changing function.

Connection Dimensions

• Frame orientation diameter: 210mm
• Frame bolt pattern: 12-M16
• Frame holes P.C.D.: 250mm
• Sprocket orientation diameter: 265mm
• Sprocket bolt pattern: 12-M14
• Sprocket holes P.C.D.: 300mm
• Flange distance: 80mm
• Approximate weight: 80kg
• Customizable flange hole patterns.

Summary

The Bonfiglioli 709 CT series Track Drive is specifically designed for closed loop applications in Skid Steer Loaders and Compact Track Loaders. It shares specifications and connection dimensions with Bonfiglioli 700 series Track Drives, ensuring interchangeability with major brands such as Sauer-Danfoss BMVT, Nabtesco TH-VB, and DANA CTL Spicer Torque-hub. Custom designs are available to match OEM specifications.

Wide Applications

The Bonfiglioli 709 CT Track Motors are compatible with a wide range of Track Loaders from leading brands including BOBCAT, CASE, CATERPILLAR, JOHN DEERE, DITCH WITCH, and more, making them versatile for various compact loader applications in the market.
