Basic Info.

• Item Fit:
• Item Condition: New
• Item Weight: 3.5-5 ton
• Item Maker: FLundercarriage
• Place of Origin: Quanzhou

Delivery Info.

• Inventory Class: Standing
• Packaging: Carton/Pallet
• ETD: 24-72 Hours
• ETA: 5-30 Days

Overview:

The WBM-700CT series Track Drive represents our latest innovation in Final Drive technology, integrating a high-efficiency hydraulic motor with a robust planetary gearbox. This versatile drive finds wide application in Skid Steer Loaders, Compact Track Loaders, Pavers, Dozers, Soil Compactors, and other Crawler Equipment.

Model Specifications:

• Rated Working Pressure: 27.5 MPa
• Max. Output Torque: 5000 N.m
• Max. Output Speed: 50 rpm
• Speed: 2-speed
• Oil Port: 5 ports

Key Features:

• Designed for closed hydraulic circuits.
• Integrated flushing valve.
• Axial Piston Motor with high efficiency.
• Double-speed Motor for versatile applications.
• Built-in parking brake enhances safety.
• Compact design with lightweight construction.
• Ensures reliable quality and durability.
• Operates smoothly with minimal noise.
• Optional automatic speed changing function.

Connection Dimensions:

• Frame orientation diameter: 210 mm
• Frame bolt pattern: 12-M14
• Frame holes P.C.D.: 244 mm
• Sprocket orientation diameter: 230 mm
• Sprocket bolt pattern: 8-M16
• Sprocket holes P.C.D.: 260 mm
• Flange distance: 75 mm
• Approximate weight: 75 kg

Customizable flange hole patterns available upon request.

Summary:

The WBM-700 series Track Drive is engineered for closed-loop applications, specifically designed for integration with Skid Steer Loaders and Compact Track Loaders. These Final Drives feature identical specifications and connection dimensions as Bonfiglioli's esteemed 700 series Track Drives, ensuring compatibility and ease of replacement. They also offer interchangeability with leading brands such as Sauer-Danfoss BMVT, Nabtesco TH-VB, and DANA CTL Spicer Torque-hub. Our flexibility extends to custom Motor sizes and connections tailored to meet OEM Final Drive requirements.

Wide Applications:

WBM Track Motors are ideal for a broad spectrum of Track Loaders from renowned brands including ASV, BOBCAT, BOXER, CASE, CATERPILLAR, and more. Designed to deliver superior performance and reliability, they excel across various industrial applications within the construction and agricultural sectors.
