Basic Info.

• Item Fit:
• Item Condition: New
• Item Weight: 2.5-3.5 ton
• Item Maker: FLundercarriage
• Place of Origin: Quanzhou

Delivery Info.

• Inventory Class: Standing
• Packaging: Carton/Pallet
• ETD: 24-72 Hours
• ETA: 5-30 Days

Overview:

The WBM-702CT Track Drive represents our latest advancement in Final Drive technology, combining a high-efficiency hydraulic motor with a robust planetary gearbox. It is extensively utilized in Skid Steer Loaders, Compact Track Loaders, Pavers, Dozers, Soil Compactors, and other Crawler Equipment.

Model Specifications:

• Max Working Pressure: 27.5 MPa
• Max. Output Torque: 3500 N.m
• Max. Output Speed: 100 rpm
• Speed: 2-speed
• Oil Port: 5 ports

Key Features:

• Designed for closed hydraulic circuits.
• Integrated flushing valve.
• Axial Piston Motor with high efficiency.
• Double-speed Motor for versatile applications.
• Built-in parking brake ensures safety.
• Compact and lightweight design.
• Promotes reliable quality and high durability.
• Operates smoothly with minimal noise.
• Optional automatic speed changing function.

Connection Dimensions:

• Frame orientation diameter: 210 mm
• Frame bolt pattern: 8-M16
• Frame holes P.C.D.: 240 mm
• Sprocket orientation diameter: 210 mm
• Sprocket bolt pattern: 12-M16
• Sprocket holes P.C.D.: 245 mm
• Flange distance: 70 mm
• Approximate weight: 60 kg

Customizable flange hole patterns available upon request.

Summary:

The WBM-700 series Track Drive is our cutting-edge solution for closed-loop applications, specifically tailored for integration into Skid Steer Loaders and Compact Track Loaders. These Final Drives share identical specifications and connection dimensions with Bonfiglioli's esteemed 700 series Track Drives, ensuring seamless compatibility and easy replacement. They are also compatible with leading brands such as Sauer-Danfoss BMVT, Nabtesco TH-VB, and DANA CTL Spicer Torque-hub. We offer flexibility to customize Motor sizes and connections to meet specific OEM Final Drive requirements.

Wide Applications:

WBM Track Motors are suitable for a wide array of Track Loaders from industry-leading brands including BOBCAT, CASE, CATERPILLAR, JOHN DEERE, DITCH WITCH, EUROCOMACH, GEHL, IHI, JCB, KOMATSU, MANITOU, MUSTANG, NEW HOLLAND, TAKEUCHI, TEREX, TORO, VERMEER, VOLVO, WACKER NEUSON, YANMAR, and other prominent Compact Loader manufacturers.
