Basic Info.

• Item Fit:
• Item Condition: New
• Item Weight: 6-8 ton
• Item Maker: FLundercarriage
• Place of Origin: Quanzhou

Delivery Info.

• Inventory Class: Standing
• Packaging: Carton/Pallet
• ETD: 24-72 Hours
• ETA: 5-30 Days

Overview:

The WBM-700CT series Track Drive represents our latest innovation in Final Drive technology, combining a high-efficiency travel motor with a robust planetary gearbox. These drives are ideally suited for Skid Steer Loaders, Compact Track Loaders, Pavers, Dozers, Soil Compactors, and other Crawler Equipment.

Model Specifications:

• Rated Working Pressure: 35 MPa
• Max. Output Torque: 8500 N.m
• Max. Output Speed: 128 rpm
• Speed: 2-speed
• Oil Port: 5 ports

Key Features:

• Designed for closed hydraulic circuits.
• Rated pressure of 35 MPa (350 bar) for high-pressure applications.
• Equipped with a speed transducer for automatic vehicle control.
• High maximum speed up to 128 rpm.
• Built-in parking brake for enhanced safety.
• Compact and lightweight design for improved maneuverability.
• Ensures reliable quality and high durability.
• Operates smoothly with minimal noise.

Connection Dimensions:

• Frame orientation diameter: 210 mm
• Frame bolt pattern: 12-M14
• Frame holes P.C.D.: 244 mm
• Sprocket orientation diameter: 230 mm
• Sprocket bolt pattern: 16-M16
• Sprocket holes P.C.D.: 260 mm
• Flange distance: 60 mm
• Approximate weight: 80 kg

Customizable flange hole patterns available upon request.

Summary:

The WBM-700 series Track Drive is our latest advancement in Travel Motors tailored for closed-loop applications. Primarily utilized in Skid Steer Loaders and Compact Track Loaders, these Final Drives boast identical specifications and connection dimensions to Bonfiglioli's renowned 700 series Track Drives. They are also compatible with other leading brands such as Sauer-Danfoss BMVT, Nabtesco TH-VB, and DANA CTL Spicer Torque-hub, ensuring seamless interchangeability and integration. We specialize in customizing Motor sizes and connections to meet specific OEM Final Drive requirements.

Wide Applications:

WBM Track Motors are suitable for a vast array of Track Loaders across major brands including BOBCAT, CASE, CATERPILLAR, JOHN DEERE, DITCH WITCH, and more. Engineered to deliver superior performance and reliability, they excel in diverse applications within the construction and agricultural sectors.
