Basic Info.

• Item Fit:
• Item Condition: New
• Item Weight: 5-7 ton
• Item Maker: FLundercarriage
• Place of Origin: Quanzhou

Delivery Info.

• Inventory Class: Standing
• Packaging: Carton/Pallet
• ETD: 24-72 Hours
• ETA: 5-30 Days

Overview:

The WBM-700CT series Track Drive represents our latest advancement in Final Drive technology, integrating a high-efficiency hydraulic motor with a robust planetary gearbox. These drives are tailored for a wide range of applications including Skid Steer Loaders, Compact Track Loaders, Pavers, Dozers, Soil Compactors, and other Crawler Equipment.

Model Specifications:

• Rated Working Pressure: 30 MPa
• Max. Output Torque: 7300 N.m
• Max. Output Speed: 80 rpm
• Speed: 2-speed
• Oil Port: 5 ports

Key Features:

• Designed for closed hydraulic circuits.
• Integrated flushing valve for enhanced performance.
• Axial Piston Motor ensures high efficiency.
• Double speed Motor with versatile application capabilities.
• Built-in parking brake for enhanced safety.
• Compact and lightweight design for improved maneuverability.
• Ensures reliable quality and high durability.
• Operates smoothly with minimal noise.
• Optional automatic speed changing function.

Connection Dimensions:

• Frame orientation diameter: 240 mm
• Frame bolt pattern: 18-M16
• Frame holes P.C.D.: 275 mm
• Sprocket orientation diameter: 250 mm
• Sprocket bolt pattern: 9-M16
• Sprocket holes P.C.D.: 290 mm
• Flange distance: 110 mm
• Approximate weight: 80 kg

Customizable flange hole patterns available upon request.

Summary:

The WBM-700 series Track Drive is our latest innovation in Travel Motors designed specifically for closed-loop applications. Primarily used in Skid Steer Loaders and Compact Track Loaders, these Final Drives share specifications and connection dimensions with Bonfiglioli's renowned 700 series Track Drives. They are also compatible with other leading brands including Sauer-Danfoss BMVT, Nabtesco TH-VB, and DANA CTL Spicer Torque-hub, offering interchangeability and ease of integration. We specialize in designing Motor sizes and connections to meet OEM Final Drive requirements.

Wide Applications:

WBM Track Motors are compatible with a wide array of Track Loaders from major brands such as BOBCAT, CASE, CATERPILLAR, JOHN DEERE, DITCH WITCH, and more. They are engineered to deliver superior performance and reliability across various applications in the construction and agricultural sectors.
